Electronic double-head cutting off machine with automatic movement of the mobile head through a C.C. motor and outward pneumatic tilting of the heads up to 45° or 22°30’, according to the model. 450 or 500 mm-blade. Equipped with an industrial computer for an optimal viewing of the cutting lists. Available with a useful cut of 4, 5, 6 m in length.
In the presence of pneumatic tilting of the moving heads, the intermediate angle viewer allows the tilting of the cutting unit to be identified with absolute precision, ensuring the accuracy of the cut profiles. Especially useful in making out-of-square cuts, it allows the operator to quickly and accurately identify the required angle.
The pneumatic intermediate support is extremely useful when cutting light profiles of considerable lengths. In this case, the pneumatic support will, automatically, provide the ideal condition to support the profile. This accessory is available for all lengths, but is specifically recommended on machines having 5- and 6-meter useful cuts.
The industrial label printer allows each cut profile to be identified with identifying features from the cutting list. In addition, barcode printing enables easy identification of the profile itself, which is particularly useful for subsequent machining steps on Machining Centres or assisted assembly lines.
