CNC 13-axis machining centre, built for milling, drilling and cutting aluminium profiles and light alloys. Optionally it may be equipped with an end milling module. QUADRA L0 is an automatic magazine with a thrust-feed system for profiles up to 7,500 mm, complete with gripper movement to block the profile. Thanks to the movement of the gripper, the feeder returns to the start position allowing the loader to prepare the next profile at the same time. The milling module, the cutting module and the optional end milling module are located in the central area of the machine. There are 4 electrospindles installed on the CNC 4-axis milling module which allow working on the whole edge of the workpiece, whichever way it faces. The cutting module is equipped with a Ø 350 blade with CNC 3-axis horizontal movement. The optional end milling module operates on two CNC axes by means of a group of cutting units. QUADRA L0 also includes an automatic ejector to transfer the workpiece from the cutting unit to the unloading magazine. The unit is composed of a transverse belts magazine to unload machined workpieces of up to 4000 mm in length (optional 7500 mm). The machining unit is equipped with a sound-proof cabin in the central operating part, which, besides protecting the operator, reduces the environmental noise impact.

Technical data arrow_drop_down
AXIS STROKES
X AXIS (longitudinal) (mm)
320
Y AXIS (transversal) (mm)
402
Z AXIS (vertical) (mm)
395
A AXIS (rotary base rotation)
0° ÷ 360°
U AXIS (bar positioning) (mm)
9660
V AXIS (gripper transversal positioning) (mm)
138
W AXIS (gripper vertical positioning) (mm)
138
C1 AXIS (pliers rotation)
0° ÷ 180°
B AXIS (motorised vice movement) (mm)
790
MILLING UNIT
Electrospindle rotary unit on rotary base
0° ÷ 360°
Electrospindles with air cooling
4
Maximum number of machining units
4
Toolholder for quick tool change (WELDON)

Maximum power in S1 (kW)
5.6
Maximum speed (rpm)
24000
Toolholder
ER 32
Disengagement from machining unit work area by means of recirculating ball slides (110 mm stroke)

Pressurised lubrication system

Heavy-duty pulsed micro-oily mist lubrication system

HORIZONTAL CUTTING UNIT
Blade diameter at carbide-tipped (mm)
350
NC blade positioning
-45° ÷ +45°
Blade motor power (kW)
0.85
Maximum rotation speed (rpm)
3500
Maximum machinable profile height (mm)
160
Maximum machinable profile width (mm)
300
FUNCTIONS
Workpiece milling, drilling, end milling and cutting directly from the entire profile, drilling and tapping at head and tail end

Multichannel management

Profile end milling

Printing labels in customised format

WORKABLE SIDES
No. of faces (top, side, bottom)
1 + 2 + 1
Head machining

MACHINING AREA OF THE MILLING UNIT
LAYOUT
Included
Avayable
Milling unit
The core and value of the QUADRA L0 lie in its rotating base machining section, complete with 4 work units that are controlled and can be interpolated on 4 axes: X, Y, Z, A (360° slewing around the axis of the bar). The work units are fitted with air-cooled high-frequency electrospindles, ER 32 tool connector with power up to 5.6 kW in S1. Each work unit can be equipped with an area disengagement system, by means of recirculating ball slides to increase the working capacity.
CNC machining centres Quadra L0 Milling unit Emmegi
CNC machining centres Quadra L0 Bar feed system Emmegi
Bar feed system
Numerically controlled, high precision and high speed bar positioning system. The system is complete with a profile clamping gripper with manual position adjustment; optionally, automatic horizontal and vertical position management on two CNC axes is possible. The belt loading magazine is used for loading profiles with length of up to 7.5 m. The movement is transmitted on a rack through a low backlash gearbox to maintain the high standards of precision guaranteed by the CNC. The feeder slides on case-hardened and tempered bars through linear bushings. The integral protection of the profile positioning carriage ensures maximum safety by limiting the area occupied by the machine in favour of more workshop space.
Label printer

The industrial label printer allows each cut profile to be identified with identifying features from the cutting list. In addition, barcode printing enables easy identification of the profile itself, which is particularly useful for subsequent machining steps on Machining Centres or assisted assembly lines.

CNC machining centres Quadra L0 Label printer Emmegi
CNC machining centres Quadra L0 Unloading magazine Emmegi
Unloading magazine
Belt magazine to discharge and store large capacity finished workpieces. Available in two versions: for processed workpieces up to 4.0 m and, as an alternative, up to 7.5 m. The unloading magazine is preceded by a swarf and short cut extraction system which can be optionally equipped with a conveyor belt and a lifting belt to the collection bag.
Horizontal cutting module
Single head cutting-off machine with a numerically controlled descending 350 mm blade and a cutting range: -45° to +45°. The setting of any cutting angle is fully automatic and CNC controlled.
CNC machining centres Quadra L0 Horizontal cutting module Emmegi
CNC machining centres Quadra L0 End milling module Emmegi
End milling module
End milling unit with cutter unit with variable rotation speed up to 8,000 rpm. With quick cutter unit tool change with pneumatic control. Interacts with the horizontal cutting unit, with which it shares the support beam. The three cutting and end milling modules are used to unload rejects into an opening, which can be fitted optionally with a steel evacuation belt.
