13 轴数控加工中心,设计用于铝和轻合金型材的铣削、钻孔和切割操作。另外可以选配一个端面铣削模块。QUADRA L0 包括一个自动刀具库和一个用于 7500 毫米及以下型材的进料系统,配有夹头运动装置,用于夹紧型材。通过夹头的移动,送料机可以返回到其初始位置,同时允许装料机准备下一个型材。在中央部分是铣削模块、切割模块以及选配的端面铣削模块。在 4 轴数控铣削模块上安装了 4 个电动主轴,无论工件的方向如何,都可以对工件的整个轮廓进行加工。切割模块安装了一个沿三个数控轴水平移动的直径 350 的刀片。选配的端面铣削模块通过铣刀组件在两个数控轴上工作。QUADRA L0 还包括一个从切割单元到卸料仓的自动提取器。该装置包括一个横向的皮带式卸料仓,用于卸载长度达 4000 毫米的工件(可以选配 7500 毫米)。加工单元的中央操作部分可以配备一个隔音舱,不仅可以保护操作员,还可以减少环境噪音。
Bar feeding

High precision and speed numerical control bar positioning system. The system is complete with profile clamping gripper with manual position adjustment; optionally it is possible to automatically manage the horizontal and vertical position on two CNC axes. The belt loading magazine allows the loading of profiles up to 7.5 m long. The transmission of the movement takes place on a rack, through a minimum clearance speed reducer to maintain the high precision standards guaranteed by the CNC. The sliding of the feeder takes place on cemented and tempered bars, by means of ball sleeves. The integral protection of the profile positioning trolley guarantees maximum safety by limiting the area occupied by the machine in favor of greater availability of space in the workshop.

CNC加工中心 Quadra L0 Bar feeding Emmegi
CNC加工中心 Quadra L0 End milling module Emmegi
End milling module

End milling unit with cutter unit with variable rotation speed up to 8,000 rpm. With quick cutter unit tool change with pneumatic con- trol. Interacts with the horizontal cutting unit, with which it shares the support beam. The three cutting and end milling modules are used to unload rejects into an opening, which can be fitted optionally with a steel evacuation belt.
